Raymarine Axiom XL 24 Glass Bridge Multifunction Display
Raymarine Axiom XL 24 Glass Bridge Multifunction Display (E70401)
Professional 24-Inch Marine Navigation System with LightHouse 4 OS and Quad-Core Performance
Experience Premium Glass Bridge Navigation with Raymarine's Flagship 24-Inch Display
The Raymarine Axiom XL 24 Glass Bridge Multifunction Display (E70401) represents the pinnacle of marine navigation technology, delivering uncompromising performance through its expansive 24-inch display and cutting-edge LightHouse 4 operating system. Engineered for serious mariners who demand the ultimate in visibility, functionality, and integration, this flagship MFD transforms your helm into a professional command center.
With its elegant edge-to-edge glass construction and quad-core processor, the Axiom XL 24 delivers lightning-fast performance while maintaining the sophisticated aesthetics demanded by modern yacht design. Whether installed in open cockpits or enclosed bridge stations, this fully waterproof system provides unmatched readability and control in all maritime conditions.
Superior Display Technology & Visibility
Advanced Visual Performance
- 24-Inch WUXGA Display: Stunning 1920 x 1200 pixel resolution with crystal-clear detail
- IPS Technology: In-plane switching delivers wider viewing angles and superior color accuracy
- Optical Bonding: Raymarine's advanced optical bonding eliminates internal reflections for unmatched readability in bright sun
- Ambient Light Sensor: Automatic display brightness adjustment based on lighting conditions
- Multi-Touch Interface: Responsive touchscreen control with intuitive gesture navigation
Professional Glass Bridge Design
- Edge-to-Edge Glass Construction: Sleek, buttonless design creates seamless helm integration
- Dual Mounting Options: Optimized for both flush and surface mounting installations
- Swipe-to-Power Control: Elegant power activation with simple touch gesture
- IPX6/IPX7 Waterproof Rating: Engineered to perform in extreme marine conditions
Flagship Performance & Processing Power
Quad-Core Processor Excellence
- Blazing-Fast Performance: Quad-core processor delivers instant response times and seamless multitasking
- LightHouse 4 Operating System: Latest software version with enhanced chart performance and reduced redraw times
- Multi-Display Network: Seamlessly integrate with additional Axiom XL, Axiom, and Axiom Pro displays
- Advanced Memory Management: Optimized performance for complex navigation tasks and data processing
Superior Connectivity & Network Integration
Comprehensive Port Configuration
- Three RayNet Ethernet Ports: Connect radar, CHIRP sonar, cameras, and additional displays
- HDMI Input/Output: Serve as remote PC display or stream to external monitors
- Integrated Wi-Fi: Connect mobile apps and cloud services
- Bluetooth Connectivity: Stream audio and alarms to remote speakers
- USB Ports: Computer control and peripheral connections
Professional Video Integration
- Four Simultaneous Video Streams: Monitor multiple camera angles simultaneously
- IP Camera Support: Connect advanced marine video systems
- FLIR Thermal Camera Integration: Enhanced awareness with ClearCruise™ thermal object recognition
- Built-in DVR Capability: Record and playback video feeds for security and analysis
- Analog Video Input: Support for traditional marine camera systems
Advanced Radar & Sonar Integration
Quantum 2 CHIRP Radar Technology
- Doppler Target Tracking: Monitor potentially dangerous targets with precision
- CHIRP Pulse Compression: Superior target separation and clarity
- Bird Mode: Track seabird activity to locate fishing opportunities
- Safety Zone Alerts: Configurable collision avoidance warnings
Professional Sonar Solutions
- RVX1000 3D CHIRP Sonar: Optional remotely mounted sonar module
- RealVision™ 3D Technology: Award-winning underwater imaging
- CHIRP DownVision: High-resolution bottom structure imaging
- CHIRP SideVision: Port and starboard underwater scanning
Vessel Automation & Digital Switching
YachtSense Technology
- Digital Switching Integration: Touch screen control of onboard electrical systems
- Engine Monitoring: Real-time engine data display and alerts
- Environmental Controls: HVAC and lighting system integration
- Security Systems: Monitor and control vessel security features
Mobile Connectivity
- RayRemote Mobile App: Control and monitor from smartphone or tablet
- LightHouse Apps: Access entertainment and marine technology partners
- Cloud Integration: Backup and sync navigation data
Technical Specifications
Display Specifications
- Screen Size: 24 inches (diagonal)
- Resolution: WUXGA 1920 x 1200 pixels
- Aspect Ratio: 16:10 widescreen
- Display Technology: IPS with optical bonding
- Touch Interface: Multi-touch capacitive
Physical Dimensions
- Width: 22.77 inches (578 mm)
- Height: 15.23 inches (387 mm)
- Mounting: Flush or surface mount compatible
- Waterproof Rating: IPX6/IPX7
Performance & Power
- Processor: Quad-core ARM
- Operating System: LightHouse 4
- Operating Voltage: 12-24V DC
- Power Consumption: [Varies by usage]
Connectivity
- RayNet Ethernet: 3 ports
- HDMI: Input/Output capability
- USB: Multiple ports
- Wi-Fi: Integrated
- Bluetooth: Audio streaming
Frequently Asked Questions
What charts come pre-loaded with the Axiom XL 24?
The Axiom XL 24 (E70401) does not include pre-loaded charts. Charts must be purchased separately from Navionics, C-MAP, or Raymarine's LightHouse chart library based on your navigation area requirements.
Can the Axiom XL 24 be installed in outdoor cockpit areas?
Yes, the Axiom XL 24 is fully waterproof with IPX6/IPX7 rating and engineered to perform in extreme conditions. It can be safely installed in both open cockpits and enclosed bridge stations.
What's the difference between LightHouse 3 and LightHouse 4?
LightHouse 4 offers enhanced chart performance with reduced redraw times, improved networking capabilities, support for LightHouse Charts Gen 2, and better integration with marine apps and systems.
How many radar and sonar devices can be connected?
With three RayNet Ethernet ports, you can connect multiple radar units, CHIRP sonar modules, cameras, and additional displays, creating a comprehensive marine electronics network.
Can I control other boat systems from the display?
Yes, through YachtSense technology and digital switching integration, you can control onboard electrical devices, engine monitoring, HVAC systems, and security features directly from the touchscreen.
Does the display support video recording?
Yes, the Axiom XL 24 includes built-in DVR capability, allowing you to record and playback video feeds from connected marine cameras for security and analysis purposes.
Ideal Marine Applications
- Luxury Yacht Navigation: Premium glass bridge installations for superyachts and motor yachts
- Sport Fishing: Advanced fish finding with 3D CHIRP sonar and video monitoring
- Commercial Vessels: Professional navigation for charter boats and working vessels
- Offshore Cruising: Long-range navigation with comprehensive safety features
- Fleet Operations: Integrated monitoring and control for commercial marine operations
Why Choose Raymarine Axiom XL 24
Flagship Performance
Quad-core processor with LightHouse 4 OS delivers the fastest, most responsive marine navigation experience available.
Professional Glass Bridge Design
Elegant edge-to-edge glass construction with buttonless design creates the perfect modern helm aesthetic.
Unmatched Integration
Superior network and video integration with three Ethernet ports supports comprehensive marine electronics systems.
All-Conditions Reliability
Engineered for extreme marine conditions with IPX6/IPX7 waterproof rating and optical bonding for bright sun readability.
Axiom XL displays offer superior performance, large format visibility and elegant simplicity. Engineered to perform in extreme conditions, the fully waterproof Axiom XL family of glass bridge chartplotters can be installed in both open cockpits and enclosed bridge stations. Each model uses in-plane switching technology (IPS) and Raymarine optical bonding to deliver wider viewing angles, sharp contrast and unmatched readability in bright sun.
Raymarine E70401 Attributes
- Maps: No Pre-Loaded Maps
- Display Size: 24 Inch
- Display Type: WUXGA 1920 x 1200 Pixels Resolution
- Interface: Touchscreen Interface
- Dimensions: 22.77 Inch Width X 15.23 inch Height
- Waterproof: IPX6/ IPX7 Waterproof
Raymarine E70401 Features & Benefits
- Flagship Performance: At The Heart Of Each Axiom XL Display Is A Blazing Fast Quad-Core Processor That Delivers A Responsive And Powerful All-In-One Big Screen Navigation Experience
- Elegant Simplicity: Axiom XL Displays Are Powered By Raymarine's LightHouse Operating System And Offer A Fast, Fluid And Uncluttered Interface That Is Easily Personalized For Your Navigation Style
- Superior Integration: A Powerful Network And Video Integration Platform, Feature Three Ethernet Ports For Connecting Radar, CHIRP And 3D Sonar Modules, Plus Additional Axiom Family Displays
- Smart And Rugged All-Glass Display Is Optimized For Flush Or Surface Mounting
- Features A Sleek Buttonless Design With Swipe-To-Power Touch Control
- Keep Watch On The Crew Or Engine Room With Marine Video Cameras
- Get Underway Faster With The Intuitive LightHouse Operating System
- Axiom XL And YachtSense Technology Offer Simple Touch Screen Control Of Onboard Electrical Devices
- Stay On Course With Evolution Autopilot Integration, Plot A Waypoint On Axiom XL And Engage Evolution's Intelligent Sensor To Keep You On The Perfect Course
- Limited 2 Year Warranty
